DS-1LN6U-W-CCA-305-m-CAT6-UTP-Network-Cable-(CCA0.565-mm)

Hikvision DS-1LN6U-W/CCA Cat 6 Network Cable

  • 305 m cost-effective CAT6 CCA network cable
  • Full diameter and full length
  • Quality verified by Fluke test
  • Guaranteed long PoE transmission distance

MRP. 1,500.00৳

SKU: DS-1LN6U-W-CCA Categories: , , , Tags: ,
Hikvision
General
Core Color 1 Blue & White/ Blue 2 Orange & White/ Orange,3 Green & White/ Green 4
Brown & White/ Brown
Packing Carton
Carton Dimension 41x41x24cm
Packing Length  (305±1.5)m
Rip-Cord Yes
Drain Wire No
Conductor
Material CCA（Copper content：27%）
Nom.O.D.(Mm) 0.585±0.01
Insulation
Material Solid  HDPE
Diameter 0.98 ± 0.05 mm
Sheath Physical Properties
Before Aging Tensile strength ≥ 13.5 Mpa
Elongation ≥ 150%
Aging Period (℃×hrs) 100℃×24h×7d
After Aging Tensile strength ≥ 12.5 Mpa
Elongation ≥ 125%
variance ratio ±25%
Cold Bend -20 ± 2°C × 4h, 8 × cable O.D, no visible cracks
Electrical Characteristics(20℃)
1.0-250.0 MHz Impedance 100 ± 15 Ω @ ≤ 100 MHz
100 ± 25 Ω @100-250 MHz
1.0-250.0 Mhz Delay Skew ≤ 45 ns/100 m
DC Resistance Ω/100m) max 12
Sheath
Thickness 0.50±0.05 mm
External O.D. 6.0±0.30 mm
Surface Clean, Frap, Satiation
Material 6.0±0.30 mm
Color White RAL9003
Surface Printing
Letter Height 2.5±0.2mm
Color Black
Print Error & Space ≤±0.5%，1m
What is the price of Hikvision DS-1LN6U-W/CCA Cat 6 Network Cable in Bangladesh?
The latest price of Hikvision DS-1LN6U-W/CCA Cat 6 Network Cable in Bangladesh is

MRP. 1,500.00৳

.
