Grandstream GWN7603 Dual-Band Wi-Fi 5 Access Point with Integrated PoE Switch

  • Up to 1270Mbps aggregate wireless throughput
  • Four 1000Mbps Gigabit Ethernet ports
  • One Gigabit uplink port with PoE/PoE+ support
  • Two Gigabit Ethernet ports with PoE power sourcing (PSE)
  • Dual-band 2×2:2 MU-MIMO technology
  • Supports up to 100+ concurrent Wi-Fi clients

TBA

SKU: GWN7603 Categories: , ,
Grandstream
WIRELESS
Client Devices 100+
2.4G Throughput 300Mbps (2×2:2 MU-MIMO); 400 Mbps with 256-QAM
5G Throughput 867Mbps (2×2:2 MU-MIMO)
6G Throughput N/A
Range Up to 100 Meters
Wi-Fi Standards IEEE 802.11a/b/g/n/ac (Wave-2)
SSIDs 16 SSIDs total, 8 per radio (2.4Ghz and 5Ghz)
Antennas 2 dual band internal antennas
INTERFACES
Network Interfaces 1 x 10/100/1000M uplink Ethernet port with POE/POE+
2 x 10/100/1000M Ethernet port with PSE
1 x 10/100/1000M Ethernet port
PoE/PoE+ Supports PoE 802.3af/ 802.3at
PSE max output per port: 12W
Max Consumption: 6.5W (Excluding PoE Output)
SECURITY
Wi-Fi and Security Systems WEP, WPA/WPA2-PSK
WPA/WPA2 Enterprise (TKIP/AES)
WPA3
Anti-hacking secure boot and critical data/control lockdown via digital signatures
Unique security certificate and random default password per device
PHYSICAL
Dimensions 135mm x 115mm x 30mm
Mounting Indoor wall mount

The Grandstream GWN7603 is a compact, enterprise-grade dual-band Wi-Fi 5 (802.11ac Wave 2) access point designed for small businesses, hotels, home offices and commercial environments. It delivers up to 1270Mbps aggregate wireless throughput and features four Gigabit Ethernet ports, including one PoE/PoE+ uplink port, two ports with PoE power sourcing (PSE) for compatible devices, and one additional Gigabit Ethernet port. Featuring dual-band 2×2:2 MU-MIMO technology on both the 2.4GHz and 5GHz bands, it provides reliable wireless connectivity for more than 100 concurrent Wi-Fi clients across an approximate coverage range of 100 metres. The GWN7603 supports advanced QoS, mesh networking, captive portals and WPA3 security. Its embedded controller can manage up to 50 local GWN access points, while GDMS Networking and GWN Manager provide flexible cloud-based and on-premises network management. With its compact design and integrated PoE switching capabilities, the GWN7603 is a practical solution for small and medium-sized deployments requiring both wireless access and wired connectivity for devices such as IP phones, computers and IPTV systems.
