AVER MD330U 4K MEDICAL GRADE 30x PTZ CAMERA

The VC520 Pro2 is an expert-level conferencing system. Equipped with an 24X total zoom, advanced AVer SmartFrame, IP video streaming, single USB installation, and an extended speakerphone solution, the VC520 Pro2 brings you an extraordinary video conferencing experience.

TBA

SKU: MD330U Categories: , ,
AVer



Camera
Image Sensor 1/2.8″ 4K Exmor CMOS
Effective Picture Elements 8 Megapixels
Output Resolutions 4K/30 (IP/UVC only), 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30
Minimum Illumination 0.7 lux (IRE50, F1.6, 30fps)
S/N Ratio ≥ 50 dB
Gain Auto, Manual
Shutter Speed 1/1 to 1/10,000 sec
Exposure Control Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
White Balance Auto, Manual
Optical Zoom 30X
Viewing Angles DFOV: 75.5° (Wide) to 3.1° (Tele)HFOV: 68.0° (Wide) to 2.7° (Tele)VFOV: 41.7° (Wide) to 1.5° (Tele)
Focal Length f = 4.3 mm (Wide) to 129 mm (Tele)
Aperture (Iris) F = 1.6 (Wide) to 4.7 (Tele)
Minimum Working Distance 0.01 m (Wide), 1.2 m (Tele)
Pan / Tilt Angles Pan: ±170°, Tilt: +90° / -35°
Pan / Tilt Speed (Manual) Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
Preset Speed Pan: 200° / sec, Tilt: 200° / sec
Preset Positions 10 (IR), 256 (RS-232 / IP)
Camera Control – Protocols VISCA (RS-232 / IP), CGI (IP)
Image Processing Noise Reduction (2D / 3D), Flip, Mirror, WDR, BLC
Power Frequencies 50 Hz, 60 Hz
Speaker
Embedded Speaker Yes
SPL 77 dB SPL (1W / 1m)
Maximum SPL 90 dB SPL at 0.5 m
Microphone
Built-in Microphone 2 (Omnidirectional)
AI Noise Reduction Yes
Pickup Range 5 m
Sensitivity -33 dBFS
Frequency Response 20 Hz to 20 KHz
Maximum SPL 133 dB SPL at 0.5 m
Loop Recording
Resolution Up to 4K
Length of Video 5 minutes
Recording Modes Loop & continuous
Loop Mechanism Wipe the oldest clip
Interface
Video Outputs HDMI, IP, USB
Audio Outputs HDMI, IP, USB
General
Power Requirement AC 100 – 240V to DC 12V/3.34A
Power Consumption 36W
Dimensions (W x H x D) 168.0 x 205.0 x 126.0 mm
Net Weight 1.95 kg
Application Indoor
Tally Lamp N/A
Security Kensington Slot
Remote Control Infrared
Operating Conditions Temperature: 0 °C to +35 °C

Humidity: 20% to 80%
Storage Conditions Temperature: -20 °C to +60 °C

Humidity: 20% to 95%

IP Streaming
Resolution 4K 30fps
Network Video Compress Formats H.264, H.265
Maximum Frame Rate 4K 30fps
Network Interface 10 / 100 / 1000 Base-T
Multi-Stream Capability 2 (RTSP / Web Page), 4K 30fps (max.)
Network Protocols IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
USB
Connector USB 3.0
Video Format MJPEG, YUY2
Audio Format PCM
USB Video Class (UVC) UVC 1.1
USB Audio Class (UAC) UAC 1.0
Software Tools
IP Search and Configuration Tool Support Windows® 7 or later
Warranty
Camera 3 Years
Accessories 1 Year
Package Contents Camera, Remote Control, Power Adapter, Power Cord, Screws (x2), USB Cable, QR Code Card
What is the price of AVER MD330U 4K MEDICAL GRADE 30x PTZ CAMERA in Bangladesh?
The latest price of AVER MD330U 4K MEDICAL GRADE 30x PTZ CAMERA in Bangladesh is

TBA

.
