C-DATA CS3244GC 24GE + 4GE COMBO L2 GIGABIT MANAGED ETHERNET SWITCH

  • Comply to IEEE 802.3, IEEE 802.3u, IEEE 802.3ab standards
  • 24*10/100/1000M RJ45 adaptive ports，support Auto MDI/MDIX
  • 4*GE Combo ports
  • Support abundant L2 features such as VLAN,LLDP,QoS,ACL
  • Support CLI/SNMP/WEB UI Management





TBA

SKU: CS3244GC Categories: , ,
C-Data
Hardware Parameter
Item Parameter
Item Parameter
Downlink ports 24*10/100/1000BASE-T
MAC table size 8K
Uplink ports 4*GE Combo
Jumbo frame 10K
Console port 1 pcs
FLASH size 16MB
Switching capability 56Gbps
SDRAM size 128MB
Packets switching capability 38.68Mpps
Energy conservation design Fanless
Port buffer 4M
Power AC100-240V
Swtiching method Strorage forwarding
Power consumption 24W
LED light power ，system，Link/Act，1000M
Dimention（W*D*Hmm） 440*220*44(mm)
Enviroment parameters storage temperature：-40º to 70ºC
Certification FCC; CE;CB;UL
work temperature 0º to 50ºC
work humidity 10% to 90%
storage humidity 10% to 90%
Software Parameter
Item Parameter
Item Parameter
Jumbo Frames 10K
ACL Based on MAC source, destination MAC, MAC source and destination MAC ,MAC protocol, source IP access control
IGMP Snooping IGMP V1/V2 Snooping
on the TCP, IP, UDP, IGMP source IP, destination IP, source IP and destination IP access control
Support 256 groups Security feature VLAN
port isolation
VLAN Port based VLAN
Port +MAC+IP binding
ACCESS VLAN Port Mirroring
One-to-one
TRUNK VLAN Many-to-one
HYBRID VLAN By mirroring port transmission, receiving and sending and receiving data
DHCP Snooping Prevent illegal DHCP server
802.1Q tagged VLAN ARP attack prevention
To prevent the ARP request deception
Max.4094 VLANs To prevent the ARP reply to cheat
MAC address administration MAC address display/inquire
Network management Telnet
Static MAC settings CLI
Dynamic MAC address administration WEB (IP:192.168.1.200 ,username/password: admin/admin)
MAC address filtering Loop detection
Support loop detection
SNMP SNMP v2c;conform to RFC1902, RFC1903, RFC1904, RFC1905,RFC1906, RFC1907
Storm control Broadcast/Multicast/Unknown Unicast Storm Control
The MIB II;conform to RFC1213 Port speed limit
Egress and ingress speed limit
Ethernet MIB conform to RFC1643
The bridge MIB conform to RFC1493

The CS3244GC switch is a gigabit managed switch, which can be configured by web interface. It has 24 10/100/1000M RJ45 adaptive ports and 4 GE Combo ports. It has abundant features such as 802.1Q VLAN, IGMP Snooping, storm control, port/IP binding，port/MAC binding etc. CS3244GC is also simple and convenient to use, plug and play, and can flexibly expand home and office networks with ease.

What is the price of C-DATA CS3244GC 24GE + 4GE COMBO L2 GIGABIT MANAGED ETHERNET SWITCH in Bangladesh?
The latest price of C-DATA CS3244GC 24GE + 4GE COMBO L2 GIGABIT MANAGED ETHERNET SWITCH in Bangladesh is

TBA

.
